Metal Right Angle Ruler

Metal Right Angle Mutongi

Cast Iron Right Angle Ruler are widely used a vertical reference for inspection of workpieces and for checking squareness. Cast iron right angles has bottom and the adjacent square face finished flat and square to each other as well as the two adjacent narrow sides finished flat and square to other two faces and are parallel to each other.

Sravana Sameeralu Serial 4th PDF Download

Details

Tags

Product Parameter



Nzvimbo Yekwakabva: Hebei, China

Warranty: 1 gore

Customized rutsigiro: OEM, ODM, OBM

Zita reBrand: Storan

Model Number：2013

zvinhu: cast iron

Kunyatsoita: customized

Operation Mode: customized

Chinhu Weight: customized

Kugona: customized

zvinhu:HT200-300

Tsanangudzo: ona fomu rakabatanidzwa kana gadzirisa

Kurapa kwepamusoro: kukweshwa nemaoko kana kupera-kugaya

Foundry process：foundry process sand casting

Painting：working surface covered with pickling oil

Surface coating：pickling oil

Kushanda tembiricha: (20±5) ℃

Precision grade：1-2

Packaging: plywood bhokisi

Custom design：Available



Kutungamira nguva

Huwandu (zvidimbu)

1 - 1

> 1

Nguva yekufambisa (mazuva)

30

Kutaurirana



Product Specifications



Material: HT200-250
Specification: see attached form or customize
Surface treatment: hand-scraped or finish-milling
Foundry process: sand casting
Painting: primer pendi
Surface coating: working surface covered with pickling oil and non-working surface covered with antirust paint
Kushanda tembiricha: (20±5)℃
Precision grade: 1-2
Packaging: plywood box



Product Parameter





No.





Size（mm)

Verticality of measuring surface towards datum

Flatness of measuring surface

Flatness of datum

Precision Degree(μm)

1

2

1

2

1

2

1

300×200

11

22

4

7

6

11

2

400×300

12

25

4

8

7

12

3

500×350

15

30

5

10

8

15

4

600×400

18

35

6

12

9

18

5

800×500

20

40

7

14

10

20

6

1000×630

25

50

8

16

12

25

7

1000×750

25

50

8

16

12

25



Product Detail Drawing
