Vatongi Vakarurama

Cast Iron Straight Rulers anoshandiswa zvakanyanya kumisikidza uye kuenzanisa michina, yekutarisa uye kuona inotakura nzvimbo panguva yekukwesha maoko. Akatsigirwa nemazvo, anogona kushandiswa neakasiyana-siyana anoratidza michina yekutarisa kupfava kwepasi kwenzvimbo dzakakura dzakagadzirwa senge ndiro yepamusoro, matafura emuchina, mibhedha yelathe, nzira dzemuchina nezvimwe.

BATA ZVINO Sravana Sameeralu Serial 4th PDF Download

Details

Tags

Product Parameter

Nzvimbo Yekwakabva: Hebei, China

Warranty: 1 gore

Customized rutsigiro: OEM, ODM, OBM

Zita reBrand: Storan

Muenzaniso Nhamba: 2010

zvinhu: cast iron

Kunyatsoita: customized

Operation Mode: customized

Chinhu Weight: customized

Kugona: customized

zvinhu:HT200-300

Tsanangudzo: ona fomu rakabatanidzwa kana gadzirisa

Kurapa kwepamusoro: kukweshwa nemaoko kana kupera-kugaya

Foundry process: jecha kukanda

Painting: primer pendi

Kuvhara kwepamusoro: nzvimbo yekushanda yakafukidzwa nemafuta ekunhonga

Kushanda tembiricha: (20±5) ℃

Kunyatso giredhi:1-3

Tsika dhizaini: iripo

Packaging: plywood bhokisi

Kutungamira nguva

Huwandu (zvidimbu)	1 - 1	> 1
Nguva yekufambisa (mazuva)	30	Kutaurirana

Features

* Ⅰ shaped

* Yakagadzirwa kubva kumhando yepamusoro simbi yakakandwa.

* Kukanda kushushikana - kurerutswa kubvisa kushushikana kwemukati.

* Offered in three Grades of accuracies: Grades 0, 1 and 2.

* Normal packaging is plywood box, fine packaging case provided on request at extra cost.

Product Specifications

zvinhu: HT200-300

Specification: see attached form or customize

Surface treatment: hand-scraped or finish-milling

Foundry process: sand casting

Painting: primer pendi

Surface coating: working surface covered with pickling oil and non-working surface covered with antirust paint

Kushanda tembiricha: (20±5)℃

Precision grade :1-3

Custom design: available

Packaging: plywood box

Product Parameter

No.	Width X Length（mm)	Straightness or Flatness of Working Surface			Parallelism Between Both Working Surfaces
		Precision Degree(μm)
		1	2	3	1	2	3
1	500 × 45	6	12		9	18
2	750 × 50	8	15		12	25
3	1000 × 55	10	20		15	30
4	1200 × 60	12	24		18	36
5	1500 × 60	15	30		20	40
6	2000 × 80	20	40	80	27	54
7	2500 × 80	25	50	100	33	65	130
8	3000 × 100		60	120		78	156

Product Detail Drawing

ruler with right angle
